CAT 24 Grader Corner Tip 109-3118

 Boron Steel Construction for Corner Protection
-The CAT 24 Grader Corner Tip 109-3118 is manufactured from high-strength boron steel, delivering excellent wear resistance for motor grader moldboard corners. This end bit measures 26.7 inches in length, 8.0 inches in width, and 1.0 inch in thickness, with a height of 4.7 inches.

-The robust construction provides substantial protection for the grader blade ends, which typically experience high wear during road maintenance and site leveling operations. The boron steel composition offers an optimal balance of hardness and toughness, allowing the corner tip to withstand both abrasive wear and impact from rocks and compacted materials. The position is designed for both right-hand (RH) and left-hand (LH) mounting, offering versatile fitment options for your CAT 24 grader.

Straightforward Installation and Maintenance
This corner tip features 6 bolt holes sized for 1-inch plow bolts (28mm square shank). The bolt pattern matches CAT OEM specifications exactly, ensuring a direct fit without modification. For best results, clean the mounting surface thoroughly before starting. Then, align the corner tip with the moldboard end.  insert the 1-inch plow bolts with hardened washers. Finally, torque all nuts evenly to manufacturer specifications. The straight edge profile on both ends simplifies positioning during installation. Regular inspection of bolt tightness helps prevent loosening during extended grading operations. When wear reaches approximately 40% of the original thickness, consider replacement to protect the moldboard structure. This end bit is designed for standard durability applications, making it suitable for general-purpose grading tasks.

 Application Tips for Extended Service Life
The CAT 24 Grader Corner Tip 109-3118 performs best in moderate grading conditions such as road maintenance, site preparation, and light to medium material handling. For optimal performance, rotate the corner tip periodically to distribute wear evenly across the cutting surface. This practice helps maximize service life and maintain consistent grading quality. Additionally, check bolt torque regularly, especially during the first few hours of operation after installation. The 1.0-inch thickness provides substantial wear material, which translates to extended service intervals between replacements. For severe abrasion conditions, consider upgrading to a harder grade material or applying weld cladding to extend service life further. This corner tip is specifically engineered for CAT 24 graders, ensuring precise fitment and reliable performance.
