Product Data Sheet – John Deere 650G Cutting Edge T209348
| Parameter | Specification |
|---|---|
| Part Number | T209348 |
| Application | John Deere 650G Crawler Dozer (D7 Series) |
| Machine Type | Bulldozer |
| Blade Type | Double Bevel |
| Length | 50.25 inches |
| Width | 14.25 inches |
| Thickness | 1.25 inches |
| Bolt Diameter | 1 inch |
| Bolt 1 Length | 3.25 inches |
| Bolt 1 Quantity | 3 bolts |
| Hole 1 Quantity | 3 holes |
| Hole 1 Distance 1st to 2nd | 16.5 inches |
| Hole 1 Distance 2nd to 3rd | 16.75 inches |
| Hole 1 Distance End to 1st | 8.5 inches |
| Installation | Bolt-on |
Durable Steel Construction for Reliable Dozing Performance
The John Deere 650G Cutting Edge T209348 is a double beveled blade designed for dependable wear resistance in general dozing applications. It measures 1.25 inches thick, 14.25 inches wide, and 50.25 inches long. Additionally, the double bevel design allows operators to flip the blade when one side becomes worn. Consequently, service life effectively doubles compared to single-bevel alternatives. The heat-treated alloy steel resists abrasion from soil, gravel, and light rocky terrain. Therefore, this cutting edge is suitable for construction, landscaping, and site preparation tasks. The blade fits the D7 series crawler dozer, with a bolt pattern of 3 holes requiring 1-inch diameter bolts.
Simple Installation with 3-Bolt Pattern
Installing the John Deere 650G Cutting Edge T209348 is straightforward. Follow these steps:
-
Clean the moldboard surface thoroughly before starting.
-
Align the blade with the moldboard, matching the 3 bolt holes.
-
Insert the 1-inch diameter bolts (3.25-inch length) with hardened washers.
-
Torque all nuts evenly in a crossing pattern to manufacturer specifications.
The bolt holes feature the following spacing:
-
1st to 2nd hole: 16.5 inches
-
2nd to 3rd hole: 16.75 inches
-
End to 1st hole: 8.5 inches
These measurements match John Deere OEM specifications exactly. Therefore, no drilling or modification is required. For best results, check bolt tightness after the first few hours of operation and inspect the blade regularly for uneven wear.
Frequently Asked Questions About John Deere T209348 Cutting Edge
What are the blade dimensions? 50.25 inches long, 14.25 inches wide, and 1.25 inches thick.
What blade type is this? Double beveled reversible design.
How many bolts are required? 3 bolts of 1-inch diameter and 3.25-inch length.
What is the bolt hole spacing? 16.5″ (1st-2nd), 16.75″ (2nd-3rd), 8.5″ (end to 1st).
Which machine is this compatible with? Designed for the John Deere 650G crawler dozer (D7 series).
Can I flip this blade? Yes. The double bevel design allows reversal when one side wears.
Is weld cladding applicable? Yes, weld buildup works well for extra wear protection.
